Сменное шасси Fliegl ZWP 180 Mega ZL

Описание

Further information
Chassis Changing turntable
Fine-grained steel welded construction
Front stop, longitudinally adjustable and foldable
Pair of removable guide rollers, front and rear
4 container locks with sturdy outriggers on 20-basefor swap bodies 7.15 and 7.45
Turntable with sturdy ball bearing slewing ring
Wheel chocks with holder
Aluminum side bumper
Side collision protection set inwards, for optimum clearance to the swap body supports
Steel underride guard
Underride guard shortened for optimum clearance to the swap body supports, lighting system mounted in a protected position
Quarter-shell mudguards at the front and half-shell mudguards at the rear
Trailer drawbar Turntable
Drawbar with tested 40 mm drawbar eye
Drawbar mechanically adjustable in length by 6 x 100 mm (approx. 1700 - 2300 mm), drawbar length set to 2200 mm
Axles + suspension
SAF disc brake axles
Axle/chassis laser-measured Reduction in tire wear and fuel consumption
Air suspension
Brake system
Pgoc R Nc Isi Ri Rnsfnsn
2-line compressed air brake systemColor-coded line routing for easy servicing.
Air supply 180 liters
Spring-loaded parking brake
2 swap-proof coupling heads at the front, with connecting lines to the motor vehicle,
EBS made by Wabco, electronic brake system with EBS plug at the front, with connecting cable,
Attention: The trailer may only be towed by towing vehicles that guarantee the effectiveness of the ABS!
with lifting & lowering valve, holding function in lowering / lifting position
Wheels and tires
265/70 R19.5 tires of the manufacturer's choice
Steel rims in twin arrangement, factory silver
Electrical system
24 volt, multi-chamber lights in LED with resistor, amber LED lighting at the side, license plate lighting in LED, (Note! with certain towing vehicles, misdiagnosis may occur although the function is given)
2 white front position lights in LED
2 white/red rear lane departure lights in LED
2 x 7-pin interchangeable plugs at the front, with connecting cable,
Additional LED work light(s), at the rear on both sides, switched via reversing light
LED work lights at the front, centered between the carriers, radiating to the rear, switched via reversing light
Country of registration / plates
Germany
with Dekra approval and certificate (according to §13 EG - FGV)
24/7 service hotline
incl. loading to 2/3 stack, loading racks against deposit
Prepared for single-line license plate holder
Contour marking with reflective strips in accordance with ECE R 048, white at the sides and red at the rear
Paint finish
Frame DB 7350 nova gray10-year warranty against rusting through
Attention: Archive pictures!
