Сменное шасси Fliegl ZWP 180 Maxi

Описание

Further information
Chassis Changing turntable
Fine-grained steel welded construction
Fliegl V-Stream frame
Front stop, longitudinally adjustable and foldable
Pair of removable guide rollers, front and rear
4 container locks with sturdy outriggers on 20-basefor swap bodies 7.15 and 7.45
Turntable with sturdy ball bearing slewing ring
Wheel chocks with holder
Aluminum side collision protection (Fliegl standard)
Side collision protection set inwards, for optimum clearance to the swap body supports
Steel underride guard (Fliegl standard)
Underride guard shortened for optimum clearance to the swap body supports, lighting system mounted protected
Half-shell mudguards (front if technically possible otherwise with sheet metal cover + quarter-shell mudguards)
With anti-spray flaps behind each axle
Rubber bumper protection at the rear
Towing device trailer turntable
Towing fork with tested 40 mm towing eyeParking sockets for electrics/ ABS on towing forkBrake/electrical connection plate on towing fork, EBS and electrics removable, all connecting lines to towing vehicle as reversible flex lines
Axles+suspension
SAF disc brake axles with 430 mm disc diameter
Axle/suspension laser-measured Reduction in tire wear and fuel consumption
Air suspension
Brake system
2-line compressed air brake systemColor-coded line routing for easy servicing.
Air supply 208 liters
Spring-applied parking brake
Duomatic connection at the front, with connection line to the motor vehicle, as a spiral cable
EBS make Wabco, electronic brake system with EBS plug at the front, with connection cable detachable as spiral cable,
Attention: The trailer may only be towed by towing vehicles that guarantee the effectiveness of the ABS!
with lifting & lowering valve, holding function in lowering / lifting position + auto-reset function, quick release valves on all axles
Vehicle stability system
Axle load detection via EBS-Canbus signal, for indication via display in driver's cab, truck must be prepared accordingly, no truck installed (no calibrated scales)
Wheels and tires
385/55 R22.5 make of the manufacturer's choice
Pgsc R Nc Ifsi Ri Rgjnsn
Steel rims, factory silver
Electrical system
24 volt, multi-chamber lights in LED with resistor, amber LED lighting on the side, license plate lighting in LED, (Note! with certain towing vehicles, misdiagnoses can occur, although the function is given)
2 white front position lights in LED
2 white/red rear lane departure lights in LED
1 x 15-pin plug at the front, with connection cable detachable as spiral cable,
Additional LED work light(s) at the rear, switched via reversing light
LED work lights at the front, centered between the carriers, radiating to the rear, switched via reversing light
Country of registration / plates
Germany
with manufacturer confirmation + brake calculation
24/7 service hotline
Prepared for single-line license plate holder
Warning sign according to ECE - 70
Contour markings with reflective strips according to ECE R 048, white at the sides and red at the rear
Paint finish
Frame DB 7350 nova gray 10-year warranty against rusting through
Attention: Archive pictures!
