Сменное шасси Fliegl DWP 240

Описание

Further information
Chassis Changing turntable
Fine-grained steel welded construction
Front stop, longitudinally adjustable and foldable
2 pairs of removable guide rollers, front and rear
4 container locks with sturdy outriggers on 20-basefor swap bodies 7.15 and 7.45
Turntable with strong ball bearing slewing ring
2 wheel chocks with holder
Aluminum side bumper
Steel underride guard
Front half-shell mudguards and rear half-shell mudguards
2 stainless steel storage box, w=600/h=400/t=500 mm, with polished door, lockable
1 pair of warning signs, double LED illuminated, extendable to 3,000 mm at the rear, rear only
1 preparation plug for retrofitting warning signs at the front for customers
Towing equipment Trailer turntable
Drawbar with tested 40 mm towing eye
Drawbar mechanically adjustable in length by 6 x 100 mm and lockable (drawbar length approx. 1,900 - 2,500 mm)
Drawbar height adjustment via spring
Axles + suspension
BPW disc brake axles with 430 mm disc diameter
Axle/chassis laser-measured Reduction of tire wear and fuel consumption
Air suspension with lift & lower valve
Wheels and tires
385/55 R22,5
manufacturer's choice
Factory silver steel rims
Brake system
2-line compressed air brake system
Spring-loaded parking brake
2 interchangeable clutch heads at the front, with connecting cables to the motor vehicle,
EBS, electronic brake system with EBS plug at the front, with connecting cable
Attention: The trailer may only be towed by towing vehicles that guarantee the effectiveness of the ABS!
Electrical system
24 volt, multi-chamber lights, amber LED lighting at the side
2 white position lights at the front
2 white/red lane departure lights at the rear
Removable rotating beacon
1 additional LED work light(s) at the rear, switched via reversing light
2 LED work lights on both sides (1x left, 1x right) (switched via reversing light)
1 x 15-pin plug at the front, with connecting cable,
Country of registration / plates
Pgec R Nei Riyloc Ifnen
Country of registration: Germany
with Dekra approval and certificate (according to §13 EG - FGV)
24/7 service hotline
Prepared for single-line license plate holder
Contour marking with reflective strips in accordance with ECE R 048, white at the sides and red at the rear
Paintwork
Hot-dip galvanized frame incl. passivation 15-year warranty against rusting through
Drawbar KTL black
