Полуавтомат с низкой загрузкой
Полуавтомат с низкой загрузкой Nooteboom MCO-109-07V(V)
Год выпуска
2007
Состояние
отличное состояние (б/у)
Цена без учета НДС
Цена по запросу
Отправить сообщение
Описание
Color : Red
payload weight: 117600 kg.
Extendable
Main features
Manufacturer: Nooteboom
Model: MCO-109-07V (V)
Chassis number: XMRMC000070000199
Year: 2007
Weights/Loading Capacity
King pin load: 36,200 kg
Axle load: 15,600 kg
Total axle load: 15,600 kg x 7 =109,200 kg
Pscjuu Hf Ho R Nc Ifnsgn
GVW: 145,400 kg
Empty weight: 27,800 kg
Loading capacity: 117,600 kg
Axles
Brand Axles: BPW
Hydraulic suspension
Axles 1, 2 and 3 lifting
Axles 1 & 2 rigid
Axles 3-7 hydraulic steering
Tires: 245/70R17.5, double fitted
Dimensions
Length: 17,155 mm
Extension: +10,100 mm + 10,100 mm
Max extended length: 37,355 mm
Loading floor length: 12,850 mm
Loading floor width: 3,240 mm
Height: 1,065 mm empty, 1,040 mm loaded.
(+135 mm, -145 mm)
King pin height: 1,355 mm
Additional Information
NATO connection
Remote control steering
Spare wheel + spare wheel holder
King pin 3.5"
Hydraulic operated gooseneck
Boards at gooseneck
Lashing rings
Central greasing
Toolbox at gooseneck
Fresh paint job
Technically serviced
New tires
= Additional Information =
General Information
Year of manufacture: 2007
Axle configuration
Tire size: 245/70R17.5
Axle brand: BPW
Suspension: Hydraulic suspension
Rear axle 1: Twin tires; Lift axle; Max. axle load: 11,200 kg
Rear axle 2: Twin tires; Lift axle; Max. axle load: 11,200 kg
Rear axle 3: Twin tires; Lift axle; Max. Axle load: 11,200 kg; Steered
Rear axle 4: Twin tires; Max. axle load: 11,200 kg; Steered
Rear axle 5: Twin tires; Max. axle load: 11,200 kg; Steered
Rear axle 6: Twin tires; Max. axle load: 11,200 kg; Steered
Rear axle 7: Max. axle load: 11,200 kg; Steered
Dimensions
Dimensions (L x W x H): 1716 x 324 x 107 cm
Weights
Unladen weight: 27,800 kg
Payload: 117,600 kg
GVW: 145,400 kg
Functional
Extendable body: Yes
Condition
Technical condition: very good
Visual condition: very good
Damage: none
Further information
Contact Stefan Schaapveld for more information.
Характеристики
Цвет
красный
Конфигурация осей
3 оси
Размер шины
245/70R17,5
Колесная база
1 510 мм
Подвеска
гидравлика
