Полуприцеп-контейнеровоз (шасси)
Полуприцеп-контейнеровоз (шасси) FLIEGL 3-Achs Containerchassis Vario V3
Год выпуска
2022
Состояние
б/у
Цена без учета НДС
4230160.00
Отправить сообщение
Описание
Chassis semi-trailer for containersFine-grain steel welded construction, fifth wheel plate with replaceable 2" kingpin and two kingpin positions
Container mounts:
Rear extension retracted: 1 x 20-foot or 1 x 30-foot flush with the rear
New locking positions for improved fifth wheel pressure with 20' containers flush at the rear
Lighting system at the rear, protected and recessed into the rear panel
Middle telescopic section, first stage; rear extension extended, first stage: 2 x 20-foot or 1 x 40-foot without gooseneck tunnel
Middle telescopic section, first stage; rear extension extended, first stage: 1 x 40-foot with gooseneck tunnel
Dwoc Ejww Iczjd Ddceb
Middle telescopic section, second stage; rear extension extended, second stage: 1 x 45-foot with gooseneck tunnel, with rear overhang
Middle telescopic section, second stage; front extension extended, first stage; rear extension extended, second stage: 1 x 45-foot with long gooseneck tunnel and beveled corners
Middle telescopic section as telescoping central pipe frame with bolt locking
Transport of filled tank containers is excluded.
With rear height adjustment in "hot-dip galvanized version" and folding central supports for containers without tunnel
Plug-in container guider at the front
Front cross member with latest Vario V3+ New Generation locking mechanism
Front extension mounted on rollers, manually extendable (for 45' containers with long tunnel)
Rear extension mounted on rollers, with manual crank
24-ton, 2-speed landing gear, single-sided operation, with straight lower section, without load compensation
2 wheel chocks with holders
Aluminum side underrun protection
Galvanized steel underrun protection
Extendable underrun protection for 45-foot containers
Full-width rear mudflap (not available with forklift holder)
Half-shell mudguards
With EC-compliant anti-spray mudflaps
Rear impact guard
Spare wheel holder for 1 single wheel, with fastening kit
1 storage box for fire extinguisher up to 6 kg
1 fire extinguisher (ABC powder, 6 kg)
Характеристики
Общий вес
38 000 кг
Собственный вес
4 983 кг
Максимальная грузоподъёмность
33 017 кг
Цвет
светло-зелёный
Первая регистрация
11/2022
Конфигурация осей
3 оси
Размер шины
385/55 R22.5"
Следующая проверка (TÜV)
12/2025
Подвеска
воздух
