Описание
Color: Red
Main Features
Manufacturer: Scheuerle Kamag
Units: K2506, K2506 SP8, PPU 460 HP/ Tier 4
Drive: 12x08x12
Year: 2010
VIN K2506: W09250627APKB3085
VIN K2506 SP8: W09250627APKB3099
VIN PPU: W09Z34119APKB3101
Operating hours: approx. 2640 h
Dimensions and Weights K25
Total length: 9,360 mm
Coupled length: 9,000 mm
Width: 3,000 mm
Height: 1,175 mm
Hydraulic stroke: 300 mm
Axle distance: 1,500 mm
Axle load: 36,000 kg
GVW: 216,000 kg
Empty weight: 20,000 kg
Loading capacity: 196,000 kg
Equipped with
Axles
Brand: BPW
Type: NRDZFP 10910
Year: 2010
Tyres
8 tyres per axle line
215/75R17.5, load index: 135/133k
Suspension
SCHEUERLE Hydraulic Suspension
Pscewrdmxs R Nc Ifnjgn
= Further Information =
General Information
Year of manufacture: 2010
Axle configuration
Tire size: 215/75R17.5, load index: 135/133k
Axle brand: BPW
Front axle 1: Lift axle
Front axle 2: Twin tyres; lift axle; steered
Front axle 3: Twin tyres; lift axle; steered
Front axle 4: Twin tyres; lift axle; steered
Front axle 5: Twin tyres; lift axle; steered
Front axle 6: Lift axle
Rear axle 1: Twin tyres; lift axle; steered
Rear axle 2: Twin tyres; lift axle; steered
Rear axle 3: Twin tyres; lift axle; steered
Rear axle 4: Twin tyres; lift axle; steered
Rear axle 5: Twin tyres; lift axle; steered
Rear axle 6: Twin tyres; lift axle; steered
Dimensions
Dimensions (L x W): 900 x 300 cm
Weights
Empty weight: 40,000 kg
Payload: 392,000 kg
Gross vehicle weight: 432,000 kg
Functional
Loading platform height: 117 cm
Condition
Technical condition: very good
Visual condition: very good
Further information
Contact Stefan Schaapveld for more information.
