Шасси Fliegl SDS 390 Fahrgestell für nachträglichen Tankaufbau

Описание

Further information
Fine-grained steel welded construction in lightweight design, saddle plate with replaceable 2 kingpins, only 2 longitudinal beams as double T-beams for retrofitting connecting gallows at the front in new/current design, outer frame slightly slanted with load-lock profile for attaching tension beltsNote! to attach the belts in conjunction with drop sides, the drop sides must be opened! 24 t. 2-speed support winch, single-sided operation, with straight lower section, without thrust compensation, wheel chocks with holder, aluminium side bumper, foldable,
galvanized steel underride guard, extendable, half-shell mudguards!!! enclosed loose, not mounted!!!, with anti-spray flaps behind each axle, 1 plastic water barrel, capacity approx. 30l, in FR left
BPW disc brake axles with 430 mm disc diameter, axle/chassis laser-measured Reduction of tire wear and fuel consumption, air suspension, 1st axle automatic lift axle, can also be lowered manually, can be operated with a hand button on the vehicle
2-line compressed air brake system, with 1 air reservoir central standard, spring-loaded parking brake, 2 interchangeable coupling heads at the front, without connecting cable, EBS, electronic brake system with EBS socket at the front, without connecting cable, EBS 2S/2M, test connection for brake cylinder pressure on the EBS module laid to the outside, Attention: The trailer vehicle may only be towed by towing vehicles that guarantee the effectiveness of the ABS! with lifting & lowering valve, control unit + brake integrated in frame as with tipper semi-trailer, mounted in front of the axles
Brake pad wear indicator for disc brakes via ABS/EBS lamp Truck
385/65 R22.5 Continental tires, steel rims, factory silver
Pgsc R Nc Isi Riwqofnsn
24 volt, multi-chamber lights, amber LED lighting at the side as for tipper semi-trailer, dimension 3000 mm must be observed, 2 white LED position lights at the front, loose, 2 white/red lane departure lights at the rear, 2 x 7-pin interchangeable sockets at the front, without connecting cable
Germany, test approval according to EC 2007/46 for complete vehicle, 24/7 service hotline, prepared for double license plate holder single-line1 x plastic and 1 x stainless steel interchangeable holder
Warning sign according to ECE - 70, aluminum, loose, EBS, safe parking, without contour marking / reflective strips according to ECE R 048,
Frame: DB 7350 nova gray, support legs: black coated
Available immediately!
