Низкорамный полуприцеп FAYMONVILLE MAX Trailer MAX110 Semi-Tieflader

Описание

Further vehicles available at
Excerpts from the equipment list. Complete specification upon request.
Gooseneck
* With hardwood flooring approx. 30 mm thick. Gooseneck straight at the rear
* 3 pairs of lashing rings (LC 5,000 daN)
Platform
* Extendable version
* 5 pairs of folding external lashing rings (LC 5,000 daN)
* 3 pairs of folding external lashing rings (LC 10,000 daN)
* 1 pair of recessed lashing rings at the front in the platform (LC 10,000 daN)
* Cutouts in the outer frame of the platform for attaching tension belts (LC 2,000 daN)
* Hardwood flooring approx. 48 mm thick, chequer plate above axles
Landing Legs
* JOST mechanical landing legs, 2-speed gearbox, lifting capacity approx. 24 t (test load approx. 50 t)
Tyres
* 205/65 R 17.5
Axles
* BPW axles and suspension
* 1st axle fixed, all other axles hydro-mechanically steered
* Air suspension with lift/lower valve
Braking system
* According to EU regulations with EBS-E (4S3M) without connecting cables to the tractor unit
Steel Structure
Pgoc R Nev Etx Eoc Ifnon
* Made from high-strength fine-grained steels
* Steel grades: S355J2+N/S355MC (yield strength 355 MPa), S690QL/S700MC (yield strength 690 MPa)
Paintwork
* Top-class, long-lasting corrosion protection on the shot-blasted welded frame, guaranteed by a two-component (2K) zinc dust primer
* High-quality two-component (2K) top coat, single colour RAL 3002 carmine red
* Wheels in silver
Accessories included
* 2-inch kingpin
* Galvanized steel headboard, approx. 400 mm high
* Yellow-red air couplings on the galvanized front connection bar
* 4 wheel chocks with holders on the headboard
* Spare wheel carrier in front of the headboard
* Electro-hydraulic power unit
* Remote axle steering from front and rear via cable remote control with push-buttons, includes axle alignment monitoring (without installation in the tractor unit)
* European reflector boards (red-yellow) at the rear of the trailer
* Yellow reflective tape in compliance with EU regulations on the sides, extendable section, and rear of the trailer
* Mounting brackets for warning signs with socket at both sides of the gooseneck and rear panel
* Bracket for a revolving warning beacon at the rear of the trailer
* Galvanised folding supports under the tapered section of the platform
* Load gauge for determining axle loads, including load diagram
* 7 pairs of WADER container pockets for: 1x 20' or 1x 40' container on the platform, 1x 40' container over the gooseneck, or 2x 20' containers
* Support block with 1 pair of WADER container pockets, permissible fifth wheel load approx. 20,000 kg
* 7 pairs of stake pockets for plug-in stakes approx. 100 x 50 mm in the outer frame of the platform
* Galvanised extendable widening sections by approx. 230 mm each side
* Adjustable hanging rails for aluminium loading ramps at the rear of the vehicle
* 1 pair of recessed lashing rings along the central beam at the rear of the platform (LC 10,000 daN)
* 2 pairs of ferry rings under the gooseneck and 2 pairs at the rear
* BEKAMAX (Pico) central lubrication system with normal grease NLGI-2 and removable pump protection
* 2 LED reversing lights mounted at rear
* Acoustic reverse warning signal
* HRM Metallisation (High Resistance Metallisation)
