Вакуумная автоцистерна MERCEDES-BENZ AROCS 2548 L 6x2 / KROLL Wasserrückgewinner WRS1

Описание

++ RENT ++ BUY ++ RENT ++ BUY ++ RENT ++ BUY ++ RENT ++ BUY ++ RENT
Internal number: #484
Mercedes-Benz Arocs 6x2 L with combined high-pressure rinsing and suction-pressure tank mounting with water recovery KROLL Type K 1.0-13.0/29 P
Body KROLL Fahrzeugbau-Umwelttechnik GmbH
* HOSE STORAGE CASSETTE WITH SIMULTANEOUS TELESCOPIC BOOM DN 125
* Reach stop side 5,200 mm
* Tank material S355J2+N (St. 52.3)
* Water reclaimer
* Extension piston with 3 locking points
* (3,300 l water/10,600 l sludge, 5,500 l water/8,200 l sludge, 7,700 l water/6,000 l sludge)
* Suction from open waters possible "comfort version" via cassette boom with integrated filter
* DRAINING: by means of a pneumatically actuated piston
* MUD WATER DRAIN DN 80: for pushing back the dirty water via the boom into the sewer.
* Manhole DN500
Mercedes-Benz Arocs chassis
* 2548 L 6x2
* Powershift 3
* 476PS/350KW
* EURO 6e
* Fuel capacity 510l
* Color cab MB 9147 Arctic white
* 2x LED rotating beacons on the cab
* Reversing camera
* Navigation
* Air conditioning
Vacuum system
* Samson Truck Master 2.500 approx. 2,465 cbm/h at 400 bar
* Drive: flexible, via cardan shafts, V-belts and pneumatically switchable friction clutch from the auxiliary drive of the vehicle engine.
* approx. 20m HD hose DN 125
* HOSE STORAGE CASSETTE WITH SIMULTANEOUS TELESCOPIC BOOM DN 125
* Reach stop side 5,200 mm
* Additional suction hose hoses with suction at the right rear with approx. 30 m DN 80 suction hose
High pressure system
* Uraca P 3-45 approx. 345 l/min at 205 bar
* Drive : elastic, via cardan shafts, V-belt and pneumatically switchable friction clutch.
* approx. 240m HP hose DN 25
* Large HP hose reel for 240m 1? DN 25 180° swivel
* Equipped with 240m DN 25
* small HP hose reel for 80m ?? DN 13 hydraulic
* equipped with 60m DN13
Special features
* Hose storage cassette with telescopic boom DN 125
* Infinitely variable height adjustment of the suction hose hydraulically via roller guide carriage
* Hydraulic and telescopic extension arm for suction hose that can be swiveled through 180
* KROLL water recovery WRS1 with self-cleaning function
* Pressure-speed control
* Spray gun
* LED rotating beacons
* LED ambient lighting
* Remote control of work functions via CAN-BUS technology
* CAN radio remote control
* Hand washing device (warm)
* Reversing camera with 7? color monitor incl. day/night switching
* Sound insulation paneling in front of pump room
* WATER MANAGEMENT WARNING SYSTEM: with buzzer in the main control cabinet and automatic pump shutdown.
* Residual water drainage: pneumatic for all water-bearing parts with connection to the truck compressed air system.
* Large equipment box and hose trays
* Tool box
* Holder for traffic cone
* vice
* ladder
* Electric cable winch
* Height safety device holder
* Cable pulley for banana/deflection device
* Large advertising boards on the right and left
* Manhole DN500
Nloc R Nc Isvh H Ewefnec
Technical data* GGW 26.000KG
* Unladen weight approx. 19,800 KG
* Length 9,880mm
* Height 3,890mm
* Width 2.550mm
* Wheelbase 4,200mm
